Steel Wire Rope Wedge Joint
This steel wire wedge joint is designed for use in cranes and other lifting applications. It provides a secure and reliable connection for steel wire ropes, ensuring optimal performance and safety.
Technical Specifications
Product Overview
Industrial Steel Wire Rope Wedge Joint
This high-strength steel wire rope wedge joint is engineered for secure and reliable connections in heavy-duty lifting, hoisting, and crane applications. Designed to ensure proper alignment and load distribution, it enhances safety and operational efficiency across demanding environments such as agricultural construction and industrial hoisting. Each unit is built for durability and long service life, meeting rigorous international quality and safety management standards.
- Quality Certifications
- ISO 9001:2008OHSAS 18001:2007ISO 14001:2004
Technical Specifications
Dimensions and Load Capacity Table
| Rope Size (mm) | Weight (KN) | B.L.L. (KN) | Net Weight (kg) |
|---|---|---|---|
| 6 | 10 | 43 | 0.56 |
| 8 | 10 | 51 | 0.77 |
| 10 | 15 | 71 | 1.01 |
| 12 | 20 | 100 | 1.77 |
| 16 | 30 | 161.3 | 4.6 |
| 20 | 50 | 249.6 | 7.9 |
| 32 | 120 | 600 | 32.9 |
| 40 | 200 | 984 | 55 |
