Sandwich Panel Production Line
This automated production line manufactures sandwich panels with various core materials. The system integrates decoiling, profiling, lamination, cutting, and stacking processes for efficient production.
Technical Specifications
Overview
High-Performance Sandwich Panel Production Line
This automated production line is engineered for the continuous manufacturing of high-quality insulated sandwich panels. Designed for versatility and precision, it supports a variety of core materials including EPS, rock wool, and glass silk floss. The integrated system streamlines the entire production workflow, from decoiling and roll forming to lamination, cutting, and stacking, ensuring efficient output for construction and industrial thermal insulation needs.
Technical Specifications
Production Capacity
4.5 m/min
Max Speed
2 m/min
Min Speed
- Plate Thickness
- 0.3 mm
- Core Thickness
- 20-300mm
- Total Power
- 30 KW
- Total Weight
- 25 ton
- Overall Dimensions
- 35000mm x 2500mm x 2600mm
Operational Features
Control System
PLC ControlledHigh PrecisionStable Operation
- Compatible Core Materials
- EPSRock WoolGlass Silk Floss
Workflow
Production Stages
- Composite Decoiling
- Roll Forming
- Laminating (Ribbon, Gelatinizing, Heating, Compounding, Crimping, Notching, Edge Trimming)
- Cutting System
- Runout Table
