Three-Position Latching Push Button Switch 24V
This three-position latching push button switch is designed for 24V systems. The latching mechanism ensures the switch remains in the selected position until manually changed, providing stable on/off control.
Technical Specifications
Product Overview
Industrial Three-Position Latching Switch
This three-position latching push button switch is engineered for demanding industrial control circuits. Built with a combination of durable zinc alloy and high-grade anti-flam plastic, it ensures reliable performance in diverse environments. The contacts feature a specialized silver alloy to resist electrical erosion, providing long-lasting operational integrity for signal and interlocking applications.
Technical Specifications
Mechanical Life (Cycles)
1,000,000 cycles
Pushbutton
500,000 cycles
Selector Switch
Electrical Life (Cycles)
5,000,000 cycles
Pushbutton
250,000 cycles
Selector Switch
- Rated Insulation Voltage
- 600 V
- Conventional Heating Current
- 10 A
- Insulation Resistance
- ≥50 MΩ
- Contact Resistance
- ≤25 mΩ
Signal Lamp Parameters
- Brightness
- 60 cd/m2
- Voltage Wave Tolerance
- ±20%
- Withstand Voltage
- AC 2.5KV/min
Compliance
- Certifications & Standards
- CEISO 9001RoHSULIEC 60947-5-1GB/T 14048.1
