Metal Indicator LED Push Button Switch with Red Lamp
This metal indicator LED push button switch is designed for electrical power applications. It features a red lamp for clear indication and is compliant with CE and RoHS standards.
Technical Specifications
Overview
Industrial Indicator Push Button
The XDL32 series metal indicator push button is designed for robust performance in industrial control circuits. It features high-grade zinc alloy construction with silver alloy contacts for excellent anti-electrical erosion properties. This versatile switch is ideal for signal, warning, and emergency control applications in AC and DC environments.
Electrical Specifications
Rated Withstanding Impulse Voltage
6 kV
Impulse Voltage
- Rated Insulation Voltage
- 600 V
- Max AC Operating Voltage
- 660 V
- Max DC Operating Voltage
- 400 V
- Short-Circuit Protection
- 10A fuse (IEC269-1/GB14048.3 compliant)
Environmental Performance
- Operating Temperature Range
- -5°C to +55°C
- Relative Humidity
- 35% to 85% RH
- Protection Rating
- IP40IP54IP65IP66IP67IP68
Mechanical Data
Mechanical Durability
| Component | Cycles |
|---|---|
| Standard Button | 3,000,000 |
| Emergency Button | 300,000 |
- Fastening Torque
- 0.8 Nm
Standards & Compliance
Compliance Standards
- IEC60947-5-1
- GB/T14048.1
- GB14048.5
- Certifications
- CERoHSISO 9001UL
