Technical Specifications
Overview
Professional Broadcast Analysis
The AT5011A Spectrum Analyzer is a professional-grade instrument engineered for precise analysis of radio and television broadcasting signals. It offers a comprehensive suite of control features including adjustable scan width, attenuation, and advanced filtering capabilities to ensure signal clarity. This reliable analyzer provides high-resolution data visualization for engineers and technicians requiring accurate signal diagnostic tools in broadcast environments.
Technical Specifications
Maximum Power Input
125 V
Max DC Voltage
104 W
Power Consumption
Broadcast Standards
- Radio Broadcasting
- Television Broadcasting
- Input Impedance
- 50 Ω
- Core Functionalities
- Marker FunctionCenter Frequency AdjustmentVideo FilteringAdjustable Scan WidthAttenuation Control
