Frequency to DC Converter
This frequency to DC converter transforms frequency signals into proportional DC voltage or current signals. It is designed for monitoring and controlling frequency-dependent parameters in applications such as motor speed control and process automation.
Technical Specifications
Product Overview
High-Precision Frequency Transduction
The QPV Frequency Transducer is engineered to convert AC or DC voltage and current inputs into stable, load-independent output signals. Utilizing advanced RMS measurement technology, it maintains high accuracy even with distorted waveforms. Designed for industrial robustness, the unit features a wide auxiliary power range and 35mm DIN rail mounting for seamless integration into existing control and SCADA systems.
Performance Metrics
Core Specifications
0.5 class
Accuracy Class
500 ms
Response Time
85 VAC
Min Auxiliary Voltage
265 VAC
Max Auxiliary Voltage
Technical Standards
- Regulatory Standards
- IEC 60688IEC 60255-5IEC 60255-22 Class III
Configuration & Features
System Capabilities
- 4-channel analog output
- Supports 22 parameter types
- Front panel 4-keypad configuration
- RS-485 remote data interface
- Optional SOE function
Mounting & Installation
- Installation
- 35mm DIN rail
Applications
Common Industrial Use Cases
Instrumentation PanelsControl SystemsElectrical DistributionTransmission SystemsGeneratorsSCADA Systems
