Single Pole Green Push Button Switch
This is a single pole push button switch with a green actuator and spring return. It is designed for use in control circuits up to 660V AC or 400V DC.
Technical Specifications
Product Overview
High-Performance Push Button Switch
This single-pole, spring-return push button switch is engineered for reliable control in industrial automation and machinery applications. Constructed with high-grade anti-flam plastic and specialized silver alloy contacts, it ensures high resistance to electrical erosion and long-term durability. It is ideal for controlling circuits up to 660V AC or 400V DC, making it a versatile choice for distribution cabinets, control panels, and communication networks.
Technical Parameters
Electrical Performance
600 V
Rated Insulation Voltage
10 A
Heating Current
25 mΩ
Contact Resistance
Durability
| Metric | Cycles |
|---|---|
| Mechanical Life | 1,000,000 |
| Electrical Life | 5,000,000 |
General Specifications
- Material: High-grade anti-flam plastic
- Contact Material: Special silver alloy
- Insulation Resistance: ≥50MΩ
- Brightness: 60cd/m2
- Voltage Wave Tolerance: ±20%
Compliance & Certifications
Standards Compliance
GB/T14048.1IEC60947-5-1
- Certifications
- CEISO9001ROHSUL
