Technical Specifications

Product Overview

Professional Industrial Push Button

This convex head push button switch features an integrated red LED indicator for clear signal status in industrial control circuits. Designed for high reliability, it utilizes advanced silver alloy contacts to resist electrical erosion and ensure longevity. The unit is built to withstand harsh environments with a high ingress protection rating and is fully compliant with international safety standards including IEC and CE.

Front view of the red illuminated push button switch

Electrical Specifications

Rated Insulation Voltage (Ui): 600 V
Max AC Operating Voltage: 660 V
Max DC Operating Voltage: 400 V
Rated Withstanding Impulse: 6 kV

Close up of the switch terminals and contact blocks

Mechanical Characteristics

Mounting Diameter: 22 mm
Mechanical Life: 3000000 operations
Fastening Torque: 0.8 Nm

Environmental Ratings

Protection Grade: IP65IP66IP67IP68
Operating Temperature: -5°C to +55°C
Pollution Grade: 3

Compliance

Certifications

CEISO9001RoHSUL

Standard Compliance

IEC60947-5-1
GB/T14048.1
GB14048.5

Interested in Sourcing This Product?

Submit a request to connect with verified manufacturers who produce this product.

Red LED Indicator Convex Head Push Button Switch

This push button switch has a red LED light indicator and a convex head. It is used for controlling circuits with AC voltage up to 660V and DC voltage below 400V.

Request a Quote Download PDFPDF
