Technical Specifications
Product Overview
Versatile Industrial Control
This push button series is engineered for robust industrial control, suitable for AC circuits up to 660V and DC circuits below 400V. Featuring a durable black plastic knob, the switch is constructed from zinc alloy and high-grade anti-flame materials for long-term reliability. Its high-quality silver alloy contacts ensure superior electrical conductivity and resistance to electrical erosion, making it ideal for signaling and circuit interlocking applications.
Technical Specifications
- Operating Voltage AC
- 660 V
- Operating Voltage DC
- 400 V
- Pollution Grade
- 3
- Fastening Torque
- 0.8 Nm
Environmental Conditions
- Operating Temperature Range
- -5°C to +55°C
- Air Relative Humidity
- 35% - 85% RH
Certifications & Standards
Compliance Badges
CEISO 9001RoHSUL
- Standards Met
- IEC 60947-5-1GB/T 14048.1GB 14048.5
Performance Ratings
Mechanical Life
| Switch Type | Cycles |
|---|---|
| Pushbutton | 300,000 |
| Emergency Button | 30,000 |
Protection
Protection Levels
- IP40
- IP54
- IP65
- IP66
- IP67
- IP68
