Technical Specifications
Product Overview
Professional Industrial Push Button Switch
This high-performance LED push button switch is engineered for demanding industrial control circuits, supporting AC voltages up to 660V and DC applications. Constructed with a zinc alloy body and high-grade anti-flame materials, it offers superior durability and resistance to electrical erosion. Featuring an IP67-rated waterproof design, it provides reliable protection in harsh environments while ensuring signal accuracy for warning, emergency, and control functions.
Electrical Ratings
Voltage Ratings
660 V
Max AC Voltage
400 V
Max DC Voltage
10 A
Thermal Current
Technical Specifications
Environmental Resilience
| Metric | Specification |
|---|---|
| Operating Temperature | -5°C to +55°C |
| Storage Temperature | -25°C to +70°C |
| Humidity | 35-85% RH |
| Pollution Grade | 3 |
Protection Grade
IP67IP66IP65
- Fastening Torque
- 0.8 Nm
Certifications
- Standards & Certifications
- CEISO 9001RoHSULIEC60947-5-1GB/T14048.1
