Industrial Joystick Handle with Pushbutton Switch
This industrial joystick handle features an integrated pushbutton switch. Constructed from durable plastic, it is designed for reliable operation in demanding environments.
Technical Specifications
Overview
Industrial Control Interface
This industrial joystick handle and pushbutton switch is designed for reliable operation in demanding electrical control environments. Constructed with high-grade anti-flame plastic and zinc alloy, it features special silver alloy contacts for superior resistance to electrical erosion. It is suitable for controlling circuits in machinery, automation systems, and industrial control panels, ensuring precise and comfortable operator input.
Technical Specifications
- Rated Insulation Voltage
- AC 600V (50Hz/60Hz)
- Conventional Heating Current
- 10 A
- Insulation Resistance
- ≥50MΩ
- Contact Resistance
- ≤25mΩ
- Withstand Voltage
- AC 2.5KV/min
Performance Metrics
Mechanical Life
1,000,000 cycles
Pushbutton
500,000 cycles
Selector Switch
Electrical Life
5,000,000 cycles
Pushbutton
250,000 cycles
Selector Switch
Certifications & Standards
Compliance Standards
- GB/T14048.1
- IEC60947-5-1
Certifications
CEISO 9001RoHSUL
Applications
- Suitable Environments
- Distribution BoxesControl CabinetsPower StationsCommunication Networks
