Flat Top Tower Crane
This flat top tower crane utilizes advanced technology in its design. Its structure is designed for safety and performance using three-dimensional software.
Technical Specifications
Overview
TCP5210 Flat Top Tower Crane
The TCP5210 is a high-performance flat-top tower crane engineered for efficient material handling on demanding construction sites. Its modular design facilitates rapid assembly and disassembly, significantly reducing downtime and transportation logistics. With advanced control systems and a flat-top configuration, it allows for seamless operation in congested environments where multiple cranes are required, ensuring both precision and high productivity.
Performance Metrics
Rated Hoisting Moment
60 t·m
Rated Hoisting Moment
Lifting Capacity
5 t
Max Load Capacity
1 t
Load at Max Radius
Technical Specifications
Working Parameters
| Parameter | Value |
|---|---|
| Working Radius | 2.5 - 52 m |
| Independent Hook Height | 35 m |
| Anchored Hook Height | 141.70 m |
Operational Speeds
| Function | Speed (a=2) | Speed (a=4) |
|---|---|---|
| Hoisting | 70/35/7 m/min | 35/17.5/3.5 m/min |
| Trolleying | 20/40 m/min | 20/40 m/min |
| Slewing | 0.31-0.6 r.p.m | 0.31-0.6 r.p.m |
| Traveling | 12.5-25 m/min | 12.5-25 m/min |
Power and Electrical
Mechanism Power
- Hoisting: 18/18/3.5 KW
- Trolleying: 2.2/1.5 KW
- Slewing: 2.2 x 2 KW
- Traveling: 1.7 x 2 KW
- Mains Supply
- 380V 50Hz (440V 60Hz), 150KVA
Features
- Safety Features
- Overload ProtectionAnti-collision SystemWind Speed Monitoring
