Double Head LED Light Push Button Switch
This double-head LED light push button switch provides on/off functionality. The metal switch is designed for use in controlling circuits with AC voltage up to 660V.
Technical Specifications
Overview
Industrial Double Head Push Button
This double-head LED push button switch is engineered for demanding industrial control environments. Constructed with a robust zinc alloy body and high-grade anti-flame plastic, it ensures durability and operational safety. Featuring integrated LED indication, it provides clear status monitoring for machinery control, distribution cabinets, and power stations.
Electrical Specifications
- Rated Insulation Voltage (AC)
- 600 V
- Conventional Heating Current
- 10 A
- Insulation Resistance
- ≥50MΩ
- Contact Resistance
- ≤25mΩ
Performance Metrics
Mechanical Life
1,000,000 cycles
Pushbutton
500,000 cycles
Selector Switch
Electrical Life
5,000,000 cycles
Pushbutton
250,000 cycles
Selector Switch
Compliance & Standards
Certifications
CEISO 9001RoHSUL
Standards Compliance
- GB/T14048.1
- IEC60947-5-1
Technical Details
Technical Parameters
| Parameter | Value |
|---|---|
| Withstand Voltage | AC 2.5KV/min |
| Voltage Wave | ±20% |
| Lamp Brightness | 60cd/m2 |
| Continuous Working Life | 100,000h |
