Double Head LED Illuminated Push Button Switch
This double-headed push button switch is equipped with LED illumination for clear status indication. Its IP65 rating ensures protection against dust and water, making it suitable for demanding environments.
Technical Specifications
Product Overview
Industrial Double Head LED Switch
This double-head illuminated push button switch is designed for reliable control in demanding industrial environments such as elevator control panels, distribution cabinets, and power stations. It features a robust design with an IP65 rating for high protection against dust and moisture ingress. Built with high-grade anti-flame plastics and specialized silver alloy contacts, it ensures durability and excellent electrical performance in signal and interlocking applications.
Electrical Specifications
- Rated Insulation Voltage
- 600 V
- Conventional Heating Current
- 10 A
- Contact Configuration
- N/O + N/C
- Operating Voltage Range
- 220~240V AC
Technical Parameters
Protection Grade
IP65
- Mechanical Lifespan
- 3000000 operations
- Operating Temperature
- -5°C to +55°C
- Mounting Diameter
- 22 mm
Certifications & Standards
- Standards Compliance
- CEIEC60947-5-1GB/T14048.1ISO 9001RoHSUL
