Carton Liner Poly Bag Heat Sealing Machine
Poly bag sealer for heat-sealing carton liners. This liner sealing machine works from uncuffing the bag off the carton flaps, lifting up, to heat-sealing bag top and then folding it back in carton.
Technical Specifications
Product Overview
Automated Carton Liner Sealing Solution
This fully-automatic heat sealing machine is engineered to streamline the packaging process by sealing poly liner bags directly within cartons. It performs a comprehensive sequence of uncuffing, inward folding, vacuumizing (optional), heat-sealing, and final tucking. Designed for high efficiency, this system significantly reduces labor costs and material waste while maintaining simple operation and easy adjustments.
Performance Metrics
Inserting Capacity
3 cartons/min
Minimum Rate
5 cartons/min
Maximum Rate
Technical Specifications
- Film Width Range
- 460 mm
- Max Film Width
- 840 mm
- Power Supply
- 3 phases, 7 kW
- Compressed Air
- 6 bar
- Air Consumption
- 100 NL/min
Dimensions
Applicable Carton Dimensions
| Dimension | Range |
|---|---|
| Length | 250-550 mm |
| Width | 200-400 mm |
| Height | 150-400 mm |
- Machine Dimensions (L x W x H)
- 3322 x 2177 x 2350 mm
Features
Primary Features
- Fully-automatic operation
- Optional vacuumizing function
- Customizable carton dimensions
- Reduces labor and material costs
- Easy to operate and adjust
