Automatic Carton Top Flap Folder and Sealer
This machine automatically folds the top flaps of cartons and seals them with tape. It features adjustable height and width settings to accommodate various carton sizes and ensures secure sealing for high-volume packaging applications.
Technical Specifications
Overview
Automated Carton Finishing Solution
This automatic carton top flap folder and sealer is designed to streamline packaging operations by automating the folding and sealing process. It features adjustable settings to accommodate a wide range of carton dimensions, making it suitable for versatile high-volume packaging environments. The system ensures consistent, secure closure while reducing manual labor and improving overall production efficiency.
Technical Specifications
- Maximum Carton Size (L*W*H)
- 600*500*500mm
- Minimum Carton Size (L*W*H)
- 200*150*150mm
- Compatible Tape Sizes
- 48mm60mm75mm
Performance
Conveying Speed
20 m/min
Max Speed
Electrical & Pneumatic
- Power Requirements
- 400W, 220/380V, 50/60Hz
- Operating Air Pressure
- 6 Kg/cm²
Physical Dimensions
- Machine Dimensions (L*W*H)
- 1770*850*1520mm
