Automatic Concrete Brick Production Machine
This automatic machine is designed for the efficient production of concrete bricks. It features advanced automation for consistent quality and high-volume output.
Technical Specifications
Product Overview
High-Efficiency Automatic Block Production
This fully automatic concrete brick production machine is engineered for high-volume, reliable manufacturing of various masonry products. Utilizing advanced German frequency conversion and PLC control technology, it ensures precision, energy savings, and consistent product quality. Designed for durability with heat-treated components, this system is an ideal solution for large-scale construction, landscaping, and infrastructure projects.
Performance Metrics
Daily Production Capacity
| Product Type | Shift Output (pcs) |
|---|---|
| Hollow block (400x200x200mm) | 14400-19200 |
| Solid block (240x115x53mm) | 77760-103680 |
| Interlocking block (240x115x90mm) | 31104-38880 |
| Holland brick (200x100x60-80mm) | 40320-50400 |
- Cycle Time
- 15-25 seconds
Technical Specifications
Power Ratings
48 kW
Motors Power
39.85 kW
Total Power
Hopper Volume
- Main material: 900L
- Face material: 750L
Gross Weight
- 9.0 T (without face mix device)
- 12 T (with face mix device)
- Vibration Performance
- 2940 rolls/minute (50-60 Hz) at 100kN force
Operational Details
- Compatible Raw Materials
- Crushed stoneSandCementCoal fly ashCinderSlagGangueGravelPerliteIndustrial waste
- Applied Fields
- BuildingsRoad pavingSquaresGardensLandscapingCity construction
Key Advantages
Machine Advantages
- Siemens PLC and Touch Screen control system
- Frequency Conversional Control (30% power saving)
- Double high-dynamic Proportional/Directional valves
- 360° Multi-Shaft Rotating and Compulsory Feeding
- Heat-treated moulds and parts (HRC 52-58 hardness)
