220V IP65 Green Convex Push Button Switch
This green plastic push button switch is rated for 220V and IP65, providing waterproof protection. It is designed with a convex button for easy operation in diverse electrical applications.
Technical Specifications
Overview
Professional Industrial Push Button
This XDL21-EL31 green convex push button switch is engineered for high-performance control in industrial electrical circuits. Featuring an IP65 ingress protection rating, it provides robust resistance against dust and water jets, ensuring reliable operation in demanding environments. Constructed from high-grade anti-flame plastic with silver alloy contacts, this switch guarantees long-term durability and resistance to electrical erosion.
Technical Specifications
- Rated Insulation Voltage
- AC 600V (50Hz/60Hz)
- Conventional Heating Current
- 10 A
- Insulation Resistance
- ≥50MΩ
- Contact Resistance
- ≤25mΩ
- PF Withstand Voltage
- AC 2.5KV/min
Operational Metrics
Mechanical Life
1,000,000 cycles
Push Button Cycles
500,000 cycles
Selector Cycles
Electrical Life
5,000,000 cycles
Push Button Cycles
Certification & Compliance
Standards Met
- GB/T14048.1
- IEC60947-5-1
- Certifications
- CEISO9001RoHSUL
Environmental Protection
IP Rating
IP65
Applications
Suitable Environments
- Distribution Boxes
- Distribution Cabinets
- Control Cabinets
- Power Stations
- Communication Networks
