Woven Sack Bag Inserter Machine
Bag in-serter designed for inserting liner bags in laminated and non-laminated woven polypropylene sacks. This machine automates the process of inserting bags into containers or packaging, increasing efficiency and reducing manual labor.
Technical Specifications
Overview
Automated Liner Insertion
This high-efficiency bag inserter is specifically engineered to automate the liner insertion process for woven polypropylene sacks. It is capable of handling both laminated and non-laminated bags, significantly increasing productivity on packaging lines. By streamlining the insertion workflow, this machine reduces manual labor requirements and ensures consistent, precise placement of liners for high-volume industrial applications.
Performance Metrics
Inserting Capacity
15 pcs/min
Max Capacity
Technical Specifications
Applicable Sack Dimensions
| Dimension | Range |
|---|---|
| Length | 800mm - 1200mm |
| Width | 500mm - 650mm |
- Minimum Liner Thickness
- 0.02 mm
- Power Consumption
- 2 kW
- Air Supply Requirements
- 7-8 bars, 100 m3/h
- Machine Dimensions (L x W x H)
- 6000mm x 3000mm x 1650mm
Compatibility
- Compatible Bag Types
- Woven Polypropylene SacksLaminated BagsNon-laminated Bags
