Single-Cylinder Diesel Engine
This single-cylinder diesel engine is air-cooled with direct injection. It is suitable for applications such as agricultural machinery, generators, and water pumps requiring reliable power.
Technical Specifications
Overview
Reliable Single-Cylinder Power Solutions
This series of horizontal 4-stroke single-cylinder diesel engines is designed for versatility and durability in demanding environments. Featuring efficient air-cooled or water-cooled options and direct injection technology, these engines provide consistent power for agricultural machinery, water pumps, and portable generators. With a focus on robust construction and ease of maintenance, they are an ideal choice for reliable, long-term operation.
Technical Specifications
- Engine Type
- Horizontal 4-stroke
- Cooling Method
- Water-cooled
- Starting Method
- Hand starting
- Lubrication Method
- Centrifugal lubrication with oil mist and splash
Performance Metrics
Featured Performance (R175A Model)
4.41 kW
12-Hour Rated Power
2,600 r/min
Rated Speed
0.353 L
Displacement
Technical Parameters by Model
| Model | Displacement (L) | 12-Hour Power (kW) | Net Weight (kg) |
|---|---|---|---|
| TR170 | 0.231 | 2.94 | 28 |
| TR165 | 0.199 | 2.42 | 35 |
| TR176 | 0.295 | 3.68 | 60 |
| 170A | 0.269 | 3.31 | 70 |
| R175A | 0.353 | 4.41 | 70 |
| R180A | 0.402 | 5.15 | 70 |
Applications
- Suitable Applications
- Agricultural MachineryGeneratorsWater Pumps
