Roof Sheet and Tile Roll Forming Machine
This machine efficiently produces roof sheets and tiles through a roll forming process. It is engineered with precision-aligned rollers and a robust hydraulic system for high-volume production.
Technical Specifications
Overview
Professional Roof Tile & Sheet Roll Forming Solution
The TW-7007 is a high-performance roll forming machine designed for the precise manufacturing of roof tiles and panels. Featuring a heavy-duty welded steel frame and advanced PLC frequency control, it ensures consistent output for varied material widths and thicknesses. This single-station system integrates a robust hydraulic cutting device and precision-polished rollers to provide an efficient, reliable solution for high-volume roofing production requirements.
Technical Specifications
Key Performance Metrics
15 qty
Roll Stands
15 m/min
Working Speed
5 Ton
Decoiler Capacity
Power Specifications
- Main Motor Power: 5.5 Kw
- Hydraulic Motor Power: 2.2 Kw
- Voltage: 380V, 3 Phase 50Hz
Material & Capacity
Material Handling Capabilities
| Parameter | Value |
|---|---|
| Raw Material Width | 1000mm, 1200mm |
| Thickness | 0.3 - 0.8 mm |
| Covered Width | 820mm, 1025mm |
Construction & Control
- System Features
- PLC ControlTouch ScreenHydraulic CuttingChain TransmissionChrome Coated Rollers
