Portable Gutter Forming Machine
This portable machine is designed for on-site gutter forming. It is capable of producing both K-style and half-round gutters with adjustable settings for different sizes and materials.
Technical Specifications
Overview
Professional On-Site Gutter Fabrication
This portable gutter forming machine is engineered for high-efficiency, on-site fabrication of K-style and half-round gutters. Featuring a robust welded tubular steel frame and specialized polyurethane drive rollers, it ensures consistent, precise results for contractors. With user-friendly push-button controls and safety-first wiring, this machine offers a reliable solution for various roofing projects.
Technical Specifications
Power Requirements
0.75 HP
Power
110 V
Voltage
12.8 A
Current
- Forming Speed
- 40 ft/min
- Drive System
- Polyurethane drive rollers
- Shear Mechanism
- Guillotine style double rack and gear system
- Forming Rollers
- Factory set free floating stainless steel
Material Compatibility
Material Gauge Specifications
| Material | Gauge/Thickness |
|---|---|
| Steel | 30 to 24 ga. (.3mm to .3mm) |
| Aluminum | .024 to .32 (.3mm to .8mm) |
| Copper | 16oz. to 20 oz. 3/4 hard (.5mm to .7mm) |
Material Width Capacity
- 5" Machine: 11 3/4" to 12 3/8" (300mm to 315mm)
- 6" Machine: 15" (380mm)
Safety & Controls
- Safety Features
- Push button entry/exit controlsJog featurePower interruption safety wiring
