Metal Sheet Crimping and Curving Machine for Roofing
This crimped curving machine forms curved profiles in metal sheets for roofing. It uses rollers to gradually bend the material to the desired curvature, handling various metal types and thicknesses.
Technical Specifications
Product Overview
Precision Curving Solution
This hydraulic crimped curving machine is engineered for the efficient shaping of metal sheets into precise curved profiles for roofing applications. Featuring a robust steel frame and PLC-controlled operation, it ensures consistent and accurate results for various architectural elements like arches and curved panels. The adjustable working speed and durable roller construction make it a reliable asset for industrial metal fabrication projects.
Performance Specifications
- Working Speed
- 11000 mm/min
- Total Motor Power
- 2.2 Kw
Material Capacity
- Raw Material Thickness
- 0.3 - 0.8 mm
Construction & Components
- Roller Material
- 45# forged steel
- Roller Coating
- 0.05mm hard chrome
- Shaft Diameter
- 75 mm
- Cutting Blade Material
- Cr12 mould steel (quenched)
Control System
- Control System
- PLC ControlFrequency Conversion
Machine Capabilities
Compatible Forming Types
- Crimped Curving
- Corrugated Curving
- Hydraulic Shearing
