LED Driver DC Transformer
This LED driver and DC transformer provides a stable DC power supply for LED lighting systems. It supports both 12V and 24V output, offering versatility for various lighting applications.
Technical Specifications
Overview
Compact LED Smart Driver
This ultra-thin LED smart driver is designed to provide a reliable and stable DC power supply for various LED lighting applications. Featuring a slim 15mm profile, it is ideal for space-constrained installations such as cabinet lighting and modern light fittings. The unit utilizes efficient switching power supply technology to ensure optimal energy conversion, consistent performance, and a prolonged lifespan for your connected LED fixtures.
Technical Specifications
- Model Number
- LD55-24V-40W
- Input Voltage
- 200-220V AC
- Input Frequency
- 50 Hz
- Max Input Current
- 0.5 A
Output Performance
- Output Voltage
- 24V DC
- Output Current
- 1.66 A
Physical Characteristics
- Thickness
- 15 mm
- Max Operating Temperature (tc)
- 75 °C
Certifications & Compliance
Compliance Standards
CESELVRoHS
Applications
Typical Applications
- LED Lighting Systems
- Cabinet Lighting
- General LED Fixtures
