Gutter Roll Forming Machine for K-Style and Half-Round Gutters
The Gutter Roll Forming Machine efficiently produces various gutter profiles, including K-style and half-round. This automated system progressively shapes metal strips into the desired gutter profile with precision and length control.
Technical Specifications
Overview
High-Efficiency Gutter Production
This gutter roll forming machine is engineered for the precise manufacturing of K-style and half-round gutters essential for drainage systems in steel-structured buildings. Designed for versatility and durability, the system automates the shaping of prepainted coils into accurate gutter profiles. With a robust motor and integrated hydraulic cutting system, it ensures consistent output for high-volume production requirements.
Technical Specifications
- Material Thickness
- 0.8 mm
- Max Feeding Width
- 300 mm
- Roll Forming Steps
- 16
- Max Forming Speed
- 15 m/min
- Main Motor Power
- 3 kW
Decoiler Specifications
- Decoiler Capacity
- 5 Ton
- Coil Inner Diameter
- 500-600mm
- Coil Outer Diameter
- 1800 mm
Dimensions
Machine Dimensions
| Component | Dimensions (L x W x H) |
|---|---|
| Manual Decoiler | 1.1m x 1.8m x 1.2m |
| Main Machine | 8m x 0.8m x 1.2m |
| Runout Table | 4m x 0.6m x 0.8m |
Process Flow
Production Steps
- Manual Decoiler
- Feeding Guide
- Roll Forming
- Length Measuring
- Hydraulic Cutting
- Runout Table
