Electromagnetic Flow Meter DN10-DN3200
This electromagnetic flow meter measures the volumetric flow of conductive liquids in closed conduits. It is available in sizes DN10-DN3200.
Technical Specifications
Overview
Industrial Electromagnetic Flow Meter
This electromagnetic flow meter is engineered for precise volumetric flow measurement of conductive liquids and slurries across diverse industrial sectors including water treatment, chemical processing, and food production. It features a wide measuring range scale of 1500:1 and high measurement accuracy, ensuring reliable performance in demanding environments. With options for both compact and remote configurations, along with advanced communication protocols like HART and Profibus, it integrates seamlessly into modern automation systems.
Performance Metrics
Accuracy
0.5 %
Standard Accuracy
0.2 %
High Precision Option
- Measuring Range Scale
- 1500:1
- Max Velocity of Flow
- 15 m/s
Physical Specifications
Protection Class
IP 65IP 67IP 68
- Nominal Diameter Range
- DN3 - DN3000
- Nominal Pressure
- 0.6 MPa - 4.0 MPa
Materials
- Electrode Materials
- 316LHastalloy C/BTitaniumTantalumPlatinum-IridiumTungsten Carbide Coated Stainless Steel
- Lining Materials
- NeoprenePolyurethanePTFEPFATefzel
Environmental & Electrical
Temperature Limits
- Medium Temperature: ≤80℃, ≤120℃, ≤180℃
- Ambient Temperature: -20℃ to +55℃
- Power Supply
- 85-260 VAC16-36 VDC
- Ex-proof Mark
- Ex deⅡCT6
Connectivity & Output
Output Signals
- 4-20 mA
- Pulse
- Frequency
- Contact
- Supported Protocols
- HARTProfibusRS232RS485
