Digital Panel Meter for Electrical Measurement
This digital panel meter is designed for precise electrical measurements. It features a clear display for monitoring voltage, current, and other electrical parameters.
Technical Specifications
Product Overview
High-Precision Digital Monitoring
The AM-96N series digital panel meter is a versatile instrument designed for precise electrical measurements in industrial and commercial applications. Utilizing dual-slope A/D conversion circuits and high-brightness LED displays, it provides clear and accurate monitoring of voltage, current, and power parameters. Its artistic cassette-style design ensures both aesthetic appeal and convenient installation into various electrical systems.
- Accuracy Class
- 0.5 Class
- Display Technology
- High-brightness LED
- International Certifications
- ISO 9001CECBSEMKOKEMAINMETRO
Measurement Capabilities
Measurement Functions
- AC & DC Digital Voltage Meter
- AC & DC Digital Ammeter
- Frequency Digital Meter
- AC Tri-phase Watt Meter
- AC Single-phase Watt Meter
- AC Single-phase Factor Meter
Technical Specifications by Model
| Function | Direct Input Range | Operation Voltage | Display Range |
|---|---|---|---|
| AC/DC Voltage Meter | DC 0-100V | AC 220V 50/60Hz | 0-1999 |
| AC/DC Ampere Meter | DC 0-10A / AC 10-20A | AC 220V 50/60Hz | 0-1999 |
| Frequency Meter | AC 10-2KHZ (20-300V) | AC 220V 50/60Hz | 0-1999 |
| Tri-phase Watt Meter | AC 0-100V / AC 5A | AC 380V / 220V / 110V | 0-1999 |
| Single-phase Factor Meter | AC 100-300V / AC 5A | AC 220V 50/60Hz | 0.5-0-0.5 |
Technical Features
Performance Metrics
1,999
Max Display Count
0.5 %
Accuracy Rating
60 Hz
Rated Frequency
- Circuit Design
- Dual slope, high-precision A/D conversion
- Installation Method
- Cassette setting specification for easy equipment fixing
