Corrugated Roofing Sheet Roll Forming Machine
This corrugated roofing sheet roll forming machine shapes metal sheets into corrugated profiles. It features a hydraulic cutting system and adjustable parameters for efficient production.
Technical Specifications
Overview
Professional Corrugated Roll Forming Solution
This industrial-grade roll forming machine is engineered for the high-volume production of corrugated metal roofing sheets. It features a robust, durable construction with a precision-engineered roller system that ensures consistent profile quality. Equipped with an integrated hydraulic cutting system and a programmable control interface, this machine offers efficient, automated operation for various construction and cladding applications.
Technical Specifications
- Compatible Materials
- PPGIGIAluminium
- Material Thickness
- 0.8 mm
- Drive System
- Chain driven
Performance Metrics
Key Performance Indicators
5.5 kw
Power
13 count
Roll Stations
30 m/min
Max Forming Speed
Machine Configuration
Included Components
- Manual coiler
- Adjustable input equipment
- Main roll forming machine
- Hydraulic cutting system
- Hydraulic station
- PLC Control system
Physical Dimensions
Physical Specs
| Attribute | Value |
|---|---|
| Length | 6.7 m |
| Total Weight | 5 tons |
| Shaft Diameter | 75 mm |
