Technical Specifications
Overview
High-Efficiency Roll Forming Solution
This industrial roll forming machine is engineered for the precision manufacturing of corrugated metal roofing sheets. Featuring a robust steel frame and advanced PLC control system, it delivers consistent, high-quality production for various metal types, including PPGI, GI, and aluminum. With adjustable parameters for sheet thickness and length, this equipment is a versatile and reliable solution for professional roofing material production lines.
Performance Metrics
Forming Speed
30 m/min
Forming Speed
- Power
- 7.5 kw
Technical Specifications
- Compatible Materials
- PPGIGIAluminium
- Material Thickness Range
- 0.2-0.8mm
- Roll Stations
- 22
- Drive Method
- Chain driven
- Cutting Tolerance
- 10m ±1.5mm
Construction & Dimensions
- Machine Length
- 6.7 m
- Machine Weight
- 5 tons
- Shaft Material
- 45# Steel
- Forming Roller Material
- 45# Steel (Heat treated and chromed)
System Components
Included Components
- Manual decoiler
- Adjustable input equipment
- Main roll forming machine
- Hydraulic cutting system
- Hydraulic station
- PLC Control system
