Concrete Pipe Production Machine
This machine efficiently produces concrete pipes of varying diameters, lengths, and types. Its robust construction and modular design ensure adaptability to different pipe sizes and production requirements.
Technical Specifications
Overview
High-Efficiency Concrete Pipe Production
This comprehensive production line is designed for the manufacturing of high-quality concrete pipes using both horizontal and vertical forming technologies. It offers a versatile solution for various pipe joints including flat, socket, and rabbet joints, catering to diverse infrastructure requirements. With over 23 years of manufacturing expertise behind the design, this equipment ensures reliable performance and conformity with international quality standards.
Technical Capabilities
Forming Methods
- Horizontal Type (Large Diameter)
- Vertical Type (Standard Diameter)
Horizontal Machine Range
300 mm
Min Diameter
2,400 mm
Max Diameter
5,000 mm
Max Length
Vertical Machine Range
150 mm
Min Diameter
1,000 mm
Max Diameter
1,000 mm
Max Length
Standard Compliance
Pipe Thickness Standards
| Pipe Diameter (mm) | Wall Thickness (mm) |
|---|---|
| 300 | 30 |
| 400 | 40 |
| 600 | 60 |
| 800 | 80 |
| 1,000 | 100 |
| 1,200 | 120 |
| 1,500 | 150 |
| 2,000 | 200 |
Production Line Components
Included Equipment
- Concrete Pipe Forming Machine
- Pipe Moulds
- Automatic Rolling Steel Frame Welding Machine
- Concrete Mixer (Sand/Cement/Aggregate)
- Automatic Materials Feeder
- Gantry Crane for Transport
Application & Design
- Supported Joint Types
- Flat JointSocket JointRabbet Joint
Support & Service
Technical Services
- Free design and layout planning
- Free technology support
- Free machine maintenance training
- Overseas engineering for installation guidance
- Warranty
- One year guarantee with whole-life after-sales service
Logistics
- Packaging
- Naked PackingStretch FilmCustom Requirements
Quality Assurance
Certifications
ISO 9001-2000State Standard Conformity
