60A Outdoor Non-Fusible Safety Knife Switch
This 60A non-fusible safety switch is enclosed in a robust, outdoor-rated box. It utilizes a knife switch mechanism for reliable circuit interruption and is designed for ease of use.
Technical Specifications
Overview
Reliable Outdoor Power Disconnect
This 60A outdoor non-fusible safety knife switch is engineered for residential and light commercial applications where reliable power disconnection is essential. Featuring a robust, weather-resistant enclosure with a matte-finish polyester powder coating, it ensures durability in various environmental conditions. The direct-drive mechanism provides quick-make, quick-break operation for long service life and clear ON/OFF status indication.
Technical Specifications
Rated Current
60 A
Rated Current
15 HP
Max HP Rating
Conductor Temperature Rating
- 60
- 75
- Voltage Rating
- 240 VAC
Installation & Design
- Installation Highlights
- Removable interiorAmple gutter spaceStraight-through wiringMultiple knockouts
- Security
- Yes
- Security Note
- Padlocking device allows for added security
Compliance & Usage
Suitable Applications
ResidentialLight CommercialService Entrance
- Compliance
- Suitable for service entrance equipment when installed in accordance with national electrical code
