125A Electrical Isolator Switch
This compact isolator is designed for electrical power transmission and distribution systems. Rated for up to 125A, it provides reliable isolation in circuits up to 400V AC22A.
![[copy]ETG1 125A Isolator - Image 1](/_next/image?url=https%3A%2F%2Fgiueljlssfehchxmbepc.supabase.co%2Fstorage%2Fv1%2Fobject%2Fpublic%2Fpublic-site%2Fproducts%2Fcopyetg1-125a-isolator%2F0.jpg&w=1536&q=75)
Technical Specifications
Product Overview
Compact Electrical Isolation
This modular isolator switch is designed for reliable power transmission and distribution systems. Engineered for safety and efficiency, it supports circuits up to 400V and is compliant with IEC60947-3 standards. Its compact 18mm modular design makes it suitable for a wide range of industrial and commercial electrical applications.
Technical Specifications
Rated Current
125 A
Max Rated Current
100 A
Standard Rated Current
- Number of Poles
- 2P3P4P
- Voltage Rating
- 400 V
- Modular Width
- 18 mm
Installation
Busbar Compatibility
- U type solid busbar
- Pin type solid busbar
- Mounting
- 35mm DIN rail
Compliance & Standards
Compliance
IEC60947-3AC22A
