25 Ton Mobile Hydraulic Truck Crane
This 25-ton mobile truck crane is designed for lifting and moving heavy loads in construction and industrial applications. The hydraulic crane machine features a telescopic boom for extended reach and precise control.
Technical Specifications
Product Overview
High-Reliability Mobile Crane
This 25-ton mobile hydraulic truck crane is engineered for superior versatility in construction, infrastructure, and industrial lifting tasks. It features a robust telescopic boom design with advanced hydraulic systems, ensuring smooth, efficient, and precise operation. Its compact footprint and high maneuverability allow for reliable performance in urban renewal projects, ports, and various restricted job sites.
Performance Metrics
Key Capabilities
25 t
Max Lifting Capacity
80 km/h
Max Travel Speed
40 %
Max Gradeability
34 m
Max Boom Length
Dimensions and Weight
Technical Dimensions
| Specification | Value | Unit |
|---|---|---|
| Overall Length | 12,650 | mm |
| Overall Width | 2,500 | mm |
| Overall Height | 3,380 | mm |
| Total Vehicle Mass | 29,400 | kg |
Chassis and Axle
Axle Configuration
- 6,600
- 22,800
Design Features
- Boom Characteristics
- Bi-hexagonal cross-sectionPlug-in boom headHigh-strength steel (BS700MC)Load sensitive system
