Wedge Wire Candle Filter Screen for Brewing
This candle filter screen utilizes wedge wire slot tubes for effective filtration in beer and brewing processes. It is designed for removing particulate matter and impurities, ensuring a clearer final product.
Technical Specifications
Product Overview
High-Efficiency Brewing Filtration
These wedge wire candle filter screens are engineered specifically for the demanding requirements of beer and beverage processing. Designed as a static filter element without moving parts, they offer exceptional durability and low maintenance costs. The robust construction ensures efficient particulate removal, yeast clarification, and polishing, resulting in superior product clarity and stability.
Technical Specifications
- Outer Diameter
- 33 mm
- Slot Size
- 0.05 mm
- Construction Type
- Wedge wire slot tube
Operational Details
Key Advantages
Standard Filtration Cycle
- CIP and Sterile hot water wash (85°C)
- Cooling with water
- Primary and secondary pre-coat application
- Circulation for filter bed packing
- De-aerated water push-out
- Un-filtrated beer filtration
- Filter aid sludge discharge
Design & Maintenance
Reliable Design
The system features a simple design with no moving parts, which significantly reduces the risk of mechanical failure and lowers overall maintenance costs. The candles are mounted on a perforated plate and housed within a vertical cylindrical vessel, facilitating effective backwashing with water or compressed air.
