Vertical Shaft Impact Crusher Sand Making Machine
The vertical shaft impact crusher series is optimized for stable and reliable operation with convenient maintenance. It is suitable for stone shaping and producing manufactured sand, yielding a cubic product with minimal needle content.
Technical Specifications
Overview
High-Efficiency Vertical Shaft Impact Crusher
This vertical shaft impact crusher is designed for stable, reliable operation in demanding industries such as mining, hydropower, and highway construction. It utilizes high-speed rotor technology to produce high-quality, cubic-shaped finished materials with a low needle content. Featuring an advanced PLC control system, the machine offers simplified operation and maintenance, significantly reducing downtime and operator training requirements.
Performance
Key Performance Metrics
50 t/h
Minimum Capacity
500 t/h
Maximum Capacity
30 %
Output Increase
Technical Specifications
Performance Parameters
| Item | XRVSI7611 | XRVSI8518 | XRVSI9526 | XRVSI1140 |
|---|---|---|---|---|
| Output (Waterfall Feed t/h) | 120-180 | 200-260 | 300-380 | 450-520 |
| Max Feed Size Hard (mm) | <30 | <35 | <40 | <45 |
| Motor Power (kW) | 110 | 180 | 264 | 400 |
| Weight (t) | 11.8 | 14.5 | 17.8 | 25.6 |
Features
Core Advantages
- Cubic product shape with low needle content
- Hydraulic cover-opening device for easy maintenance
- Automatic vibration monitoring and alarm system
- Thin oil lubrication station with dual pump system
- Adjustable fineness modulus for customized output
- Compliance & Standards
- ISO 9001:2015PLC ControlledVibration Protected
