Three-Phase Oil-Immersed Power Transformer
This three-phase oil-immersed power transformer is designed for voltage transformation in electrical power transmission and distribution systems. It features high-voltage bushings with porcelain insulators and a robust tank construction with cooling fins.
Technical Specifications
Product Overview
High-Efficiency Power Transformation
This three-phase oil-immersed distribution transformer is engineered for robust voltage regulation in industrial and utility power systems. Utilizing high-quality cold-rolled silicon-steel plates and oxygen-free copper windings, it delivers exceptional efficiency and reduced energy loss. The unit features advanced insulation structures and rigorous material standards to ensure short-circuit resistance and long-term operational reliability.
Technical Specifications
- Winding Material
- Oxygen-free copper
- Core Material
- Cold-rolled silicon-steel plate
- Insulation Structure
- Multilayered drum type
- Insulation Components
- Wooden laminating piecesHigh-quality rubber sealing
Key Performance Metrics
Performance Highlights
0 Low
No-load loss
1 High
Efficiency
Quality & Standards
- Quality Standards
- ISO 9000
Construction Details
Design Features
- Short-circuit resistance
- Thoroughly filtrated transformer oil
- Special fastener treatment to prevent loosening
- Leakage-resistant rubber sealing
