Single-Phase Shunt Reactor for Reactive Power Compensation
This reactor compensates for capacitance charge current of lines and inhibits capacitance effects. It limits the rising of power frequency voltage.
Technical Specifications
Product Overview
High-Efficiency Shunt Reactor
This single-phase shunt reactor is engineered for superior reactive power compensation within high-voltage electrical grids. Designed to support voltage classes up to 1100kV, the unit enhances voltage stability and significantly reduces power transmission losses. Its robust construction ensures reliable operation and improved power factor correction under demanding industrial and utility conditions.
Technical Specifications
- Voltage Class
- 1100 kV
- Maximum Capacity
- 200 MVA
Dimensions and Logistics
- Max Transport Weight (Single Unit)
- 200 ton
- Maximum Total Weight
- 345 ton
- Outline Dimensions (L x W x H)
- 13m x 11m x 18m
Performance Metrics
Key Performance Metrics
1,100 kV
Max Voltage
200 MVA
Max Capacity
