Single-Phase Oil-Immersed Distribution Transformer
These single-phase oil-filled pole-mounted distribution transformers are designed for decentralization in residential overhead distribution networks. They are also suitable for light and diversified power applications.
Technical Specifications
Product Overview
Application and Reliability
This single-phase oil-immersed distribution transformer is engineered for reliable voltage step-down in residential, commercial, and industrial power distribution networks. Designed for pole-mounted installation, it ensures efficient thermal management and stable performance under varying load conditions. It adheres to international quality standards, providing a dependable solution for modern electrical power transmission systems.
Standards and Compliance
- Certifications & Standards
- ANSI C57.12.00ANSI C57.12.20IEC76GB10138
Technical Specifications
Core Material Options
- C.R.G.O (Cold Rolled Grain Oriented) Core
- Amorphous Metal Core
Transformer Variants
- Conventional
- Complete Self-Protecting
Performance Data
Technical Parameters Table
| Capacity (kVA) | HV (kV) | LV (kV) | No-Load Loss (kW) | Weight (kg) |
|---|---|---|---|---|
| 10 | 10 | 0.23 | 0.50 | 210 |
| 20 | 10 | 0.23 | 0.70 | 270 |
| 30 | 10 | 0.23 | 0.85 | 300 |
| 50 | 10 | 0.23 | 0.14 | 350 |
Short-circuit Impedance Voltage
3.5 %
Impedance
