Semi-Automatic Gable Top Carton Filling Machine
This semi-automatic machine fills liquids into gable top cartons. It is suitable for filling milk, juice, yogurt, cream, and other beverages with precise filling volume.
Technical Specifications
Product Overview
Professional Gable Top Filling Solution
The BW-1000 semi-automatic system is a high-performance solution designed for efficient filling and sealing of gable top cartons. Constructed from 304 food-grade stainless steel, this durable system integrates carton forming, capping, and filling processes into a reliable workstation. With its PLC-controlled operation, it ensures consistent output for a wide range of liquid products, making it an ideal choice for small to medium-scale beverage producers.
Technical Specifications
Performance Highlights
1,200 cartons/hr
Maximum Output
1,000 ml
Max Fill Volume
23 kW
Total Power
1,200 kg
Total Weight
Operating Parameters
| Parameter | Specification |
|---|---|
| Fill Volume | 250-1000ml |
| Cold Fill Temp | 2-50 °C |
| Hot Fill Temp | 88-92 °C |
| Air Pressure | 1.0-1.4 Mpa |
Compatibility & Usage
- Compatible Products
- MilkYogurtCreamSoy MilkJuiceTeaWineSaucesLiquid Chemicals
Compliance & Services
Compliance Badges
CE CertifiedFood-Grade Stainless Steel12 Month Warranty
