PU Foam Insulated Shutter Door Roll Forming Machine
This machine is designed for manufacturing shutter doors with integrated polyurethane foam insulation. It shapes metal sheets using a series of rollers and injects PU foam to provide thermal insulation and structural rigidity.
Technical Specifications
Overview
High-Efficiency Shutter Door Production
This specialized roll forming machine is engineered for the high-volume production of shutter doors with integrated polyurethane (PU) foam insulation. Combining advanced roll forming technology with an integrated foam injection system, it ensures precise metal shaping and superior thermal performance. Designed for industrial and commercial reliability, the system features automated cutting and programmable control to maintain consistent quality.
Technical Parameters
Machine Dimensions
6,000 mm
Length
600 mm
Width
1,500 mm
Height
Operational Performance
9 T
Machine Weight
10 m/min
Max Working Speed
11.5 kW
Total Motor Power
Processed Material Requirements
| Property | Specification |
|---|---|
| Material Type | Galvanized Steel or Aluminum |
| Thickness Range | 0.3 - 1.0 mm |
| Yield Strength | 235 - 450 mpa |
Compliance and Quality
- Certifications
- CEISO 9001
Component Details
Production Line Components
- 2 sets Decoiler
- 3 sets Main forming machine
- 3 pcs Control panel
- 1 set Foam injection unit
- 1 set Flying sew cutting device
- 1 set Manual holder
Service and Support
Warranty and Service
- 2 years warranty period
- 24/7 online technical support
- Overseas engineer service available
- Remote video call installation/adjustment assistance
