Precision Woodworking Vise NHV-130A
This precision woodworking vise is designed for use with metal cutting machines. The NHV-130A model features a rigid ductile iron body and a flame-hardened vise bed for enhanced durability and accuracy.
Technical Specifications
Overview
High-Precision Woodworking & Metalworking Vise
The NHV-130A is a best-selling high-precision vise designed for demanding woodworking and metal cutting applications. It features a robust ductile iron body and a flame-hardened bed to maintain long-term accuracy and resist wear. Engineered for professional workshops, this manual drive vise ensures exceptional stability and secure clamping for grinding and milling operations.
Key Performance Metrics
Precision Metrics
0.008 mm
Overall Precision
0.003 mm
Parallelism per 100mm
0.005 mm
Squareness per 100mm
Construction & Material
- Body Material
- Ductile Iron FCD60 (Equal to GGG60)
- Tensile Strength
- 80000 psi
- Bed Hardness (Flame Hardened)
- HRC 45°
- Component Hardness
- HRC 52-60
Technical Specifications
- Model
- NHV-130A
- Drive Mode
- Manual
- Spindle System
- Mechanical/Hydraulic spindle without original clutch mechanism
- Compatible Machine Types
- Grinding MachineMetal Cutting MachineWoodworking Machine
Quality Standards
Certifications & Origin
CEISO 9001German Brand Components
