Power Factor Correction Controller
This power factor controller facilitates real-time measurement and monitoring of distribution system parameters. The device controls reactive power compensation circuit switching and provides protection and alarm functions.
Technical Specifications
Overview
Intelligent Power Factor Management
This advanced power factor correction controller is designed for efficient management and optimization in electrical power transmission and distribution systems. Featuring a user-friendly interface with guided menu operation, it allows for flexible control sequences and comprehensive system monitoring. The device ensures reliable performance with features like automatic memory for parameter settings and robust fault monitoring capabilities.
Technical Specifications
Monitoring Capabilities
- System parameters
- Voltage harmonics
- Current harmonics
- Individual capacitor power value
- Fault monitoring and diagnostics
- Output Capacity
- 12 or 21 outputs (configurable)
- Switching Modes
- Self-optimized intelligent controlCyclic switchingCoding switching8421 coding mode
Operational Features
Operational Modes
Manual OperationAutomatic OperationUser-defined Control Level Editor
Safety & Testing
- No voltage shutdown
- Automatic memory of setting parameters
- Fault information display
- Error analysis test operation
- Data Retention
- Yes
