Technical Specifications
Overview
Versatile Industrial I/O Coupler
This modular I/O coupler facilitates seamless communication between Modbus systems and distributed bus terminal modules. It supports both Modbus TCP and Modbus RTU protocols, allowing for flexible integration into various industrial automation environments. Designed for efficiency, the system supports automatic configuration and can be expanded with up to 64 terminal modules.
Communication Protocols
Modbus Function Codes
- 1
- 2
- 3
- 4
- 5
- 6
- 15
- 16
Ethernet Interface Features
- Static or dynamic IP acquisition
- Heartbeat and timeout disconnection
- TCP Server/Client support
- UDP support
- Supported Protocols
- Modbus TCPModbus RTUCANopen
Technical Specifications
Performance Metrics
64 units
Max Terminal Modules
115,200 bps
Max Baud Rate
1,000 Vrms
Electrical Isolation
- Power Supply
- 24V DC (-15%/+20%)
- Operating Temperature
- -40°C to 85°C
- Dimensions (L x W x H)
- 100mm x 69mm x 48mm
CANopen Features
CANopen Capabilities
4 TPDO4 RPDO1 SDOEmergency ObjectNode Error Control
