Laser Hardening System
This laser hardening system is engineered for surface treatment, specifically of cylindrical workpieces. It utilizes a robotic arm with a laser head and a rotating mechanism to ensure uniform hardening, enhancing the surface hardness and wear resistance of metal parts.
Technical Specifications
Overview
High-Efficiency Laser Surface Treatment
This laser hardening and cladding system utilizes a high-energy-density laser beam to perform rapid solid phase transitions and fusion cladding. Designed for industrial durability, it significantly enhances the wear, corrosion, and oxidation resistance of metal surfaces. The system is ideal for both surface hardening and the precision repair of worn components, offering a versatile solution for industrial maintenance and manufacturing.
Technical Capabilities
Performance Advantages
- High energy density for rapid heating
- Minimal workpiece deformation
- Precise control over heating depth and position
- Increases service life by up to 3 times
- Supports single or multi-layer cladding
- Core Functions
- Surface HardeningLaser CladdingComponent RepairWear Resistance ImprovementCorrosion Resistance Enhancement
Equipment Features
System Components
- Imported laser source
- High-efficiency composite cladding actuators
- Precision servo drive system
- Automated powder feeder
Optical System Protection
Lens Water CoolingPositive Pressure ProtectionAnti-Interference Design
Applications
Typical Applications
| Application Area | Process Type |
|---|---|
| Electric Pump Shafts | Remanufacturing |
| Internal Wall Surfaces | Cladding / Quenching |
| Steel Mill Gear Shafts | Repair / Cladding |
| Turbine Generator Blades | Quenching |
| Profile Rolls | Quenching / Cladding |
| Large Molds | Quenching |
| Seamless Steel Pipe Needles | Cladding |
