Indoor CATV Signal Amplifier
This indoor CATV signal amplifier enhances signal strength using a push-pull output stage. It features smooth gain and slope controls, along with a built-in power supply.
Technical Specifications
Overview
High-Performance Indoor Signal Distribution
This indoor CATV signal amplifier is engineered to enhance television signal strength and quality within residential or commercial buildings. Featuring a push-pull output stage and a built-in power supply, it provides stable and clear reception even in areas with weak incoming signals. The device offers precise manual controls over both gain and gain slope, making it an ideal solution for distributing high-quality signals to multiple television sets.
Key Metrics
Performance Highlights
35 dB
Gain
117 dBμV
Max Output
4 dB
Noise Figure
Technical Specifications
I/O Configuration
| Interface | Quantity/Type |
|---|---|
| Inputs | 1 |
| Outputs | 1 Main Output |
| Test Port | 1 Output Test (-30dB) |
- Frequency Range
- 47-862MHz
- Return Loss
- 12 dB
Control & Adjustment
Adjustment Ranges
- Attenuator: 0-20dB
- Equalizer: 0-20dB
- Smooth gain control
- Smooth gain slope control
Power & Hardware
- Power Supply Voltage
- AC 90-260V
- Hardware Features
- Push-Pull Output StageBuilt-in Power SupplyIndoor Rated
Service & Quality
Quality Standards
CE CertifiedDefective Rate < 0.2%Strict Quality Control
Available Services
- OEM Logo Printing
- Customized Packaging
- Software Customization
- 1-2 Year Warranty
