Gable Top Carton Filling and Sealing Machine
This machine automatically fills and seals gable-top cartons with liquids. It integrates filling, sealing, and capping functions into one unit for efficient packaging.
Technical Specifications
Overview
Integrated Gable-Top Packaging Solution
This high-efficiency liquid filling and capping system is designed for gable-top cartons, integrating three essential processes: carton forming, capping, and filling. Constructed from durable food-grade stainless steel, the machine ensures hygienic operation and longevity. It is a versatile solution suitable for a wide range of products including dairy, juices, sauces, and even dry powders, offering precise control over the entire packaging workflow.
Performance Metrics
Production Speed
1,200 cartons/hr
Max Output
- Filling Capacity
- 250 - 1000 ml
Technical Specifications
- Overall Power
- 23 KW
- Compressed Air Pressure
- 1.0 - 1.4 Mpa
- Cooling Water Flow
- 20 L/min
- Total Net Weight
- 1200 kg
Compatibility
Packaging Material
- Cardboard carton
- Aluminium foil carton
- Compatible Products
- MilkYogurtCreamBeaten EggSoy MilkJuiceTeaSauceWineDry Powder
Operational Details
Machine Dimensions
| Component | Dimensions (L*W*H) |
|---|---|
| Carton Forming | 1.3m * 0.9m * 1.5m |
| Capping Machine | 0.8m * 0.6m * 1.2m |
| Filling Machine | 2.0m * 0.9m * 2.6m |
- Filling Temperature Range
- 2-50°C (Cold) / 88-92°C (Hot)
