Technical Specifications
Overview
Automated Flour Packing Solution
This automated flour weighing and packing machine streamlines the production process by integrating filling, weighing, conveying, and sealing into a single efficient system. Designed for medium to large-scale operations, it ensures high precision and consistent throughput for powdered materials. The system supports a seamless workflow from manual bag placement to final sewing or sealing, significantly reducing labor requirements.
Core Specifications
Production Capacity
System Components
- Automatic filling system
- Automatic weighing balance
- Automatic belt conveyor
- Automatic sewing / sealing machine
- Electric control cabinet
Operational Parameters
- Weighing Range
- 50 kg
- Power Consumption
- 3 KW
- Electrical Requirements
- 380/220V, 50Hz
- Air Power
- 0.6 Mpa
- Model Type
- LCS-LX
Dimensions
Machine Dimensions
| Configuration | Dimensions (mm) |
|---|---|
| Option 1 | 1400 x 700 x 3100 |
| Option 2 | 1310 x 700 x 2600 |
