Carbonated Beverage Mixing Machine
This mixing machine is engineered for the mixing of carbonated drinks and soda. It uses stainless steel parts for food sanitation and PLC technology to control pressure and liquid levels, ensuring stable performance and high efficiency.
Technical Specifications
Product Overview
Industrial Carbonated Beverage Mixing Machine
The RY-H Series is a high-precision beverage mixing system engineered for the consistent production of carbonated drinks. Featuring advanced syrup-to-water ratio adjustment and high-purity carbonation capabilities, these units ensure reliable mixing precision within 2%. Built for industrial efficiency, the system supports varying output capacities to suit diverse production scale requirements.
Technical Specifications
Technical Data Comparison
| Model | Output | Motor Power | Weight |
|---|---|---|---|
| RY-H03 | 3T | 5.8kW | 1200kg |
| RY-H06 | 6T | 6.3kW | 1350kg |
| RY-H09 | 9T | 6.5kW | 1500kg |
| RY-H18 | 18T | 7.2kW | 1950kg |
Mixing Performance
2 %
Mixing Precision
2.5 Max
Gas/Water Ratio
Operating Requirements
Input Parameters
- Syrup and Water adjusting rate: 1:3 - 1:10
- Cooling water inlet temperature: 0 - 4°C
- Syrup inlet temperature: 2 - 8°C
- Carbon Dioxide purity: > 99.9%
Compliance
High Purity CO2 (>99.9%)Precision Mixing
