Automatic Liquid Carton Filling Machine
This automatic machine fills and seals liquid products into cartons with a high degree of precision. It is suitable for milk, juice, yogurt, cream, and other beverages.
Technical Specifications
Overview
High-Efficiency Automatic Filling Solution
This automatic liquid carton filling machine is designed for high-performance packaging of dairy and liquid products. Constructed from 304 food-grade stainless steel, it features a fully automated PLC-controlled workflow that handles everything from bottom forming and filling to top sealing and date printing. With a capacity of up to 2500 cartons per hour, it is an ideal solution for streamlining production lines with minimal manual intervention.
Performance Metrics
Production Output
2,500 cartons/hr
Max Output
1,000 ml
Max Fill Volume
Technical Specifications
- Dimensions (L x W x H)
- 3.7m x 1.6m x 2.8m
- Net Weight
- 3500 kg
- Overall Power
- 25 KW
- Filling Temperature
- 2-50 °C
Utility Requirements
Compressed Air
- Pressure: 1.0-1.4 Mpa
- Flow rate: 1.4-2 M3/min
- Requirement: Oil, water, and dust-free
- Cooling Water
- Flow volume ≥ 40L/min, Temp ≤ 30°C
Compatibility
- Suitable for
- MilkYogurtCreamSoy MilkBeaten Egg
- Packaging Materials
- Cardboard cartonAluminium foil carton
Service & Terms
Warranty
12 Months Guarantee
Payment Terms
| Method | Details |
|---|---|
| T/T | 30% deposit, 70% balance before shipment |
| L/C | At sight |
