Automatic Edible Oil Filling Machine
This automatic filling machine is designed for filling various types of oils, including edible oil, lubricating oil, peanut oil, and soybean oil. It features high automation and intelligent control for stable and reliable performance.
Technical Specifications
Overview
High-Efficiency Oil Filling Solution
This fully automatic filling machine is engineered specifically for the high-speed, precise filling of edible and lubricating oils. Featuring an integrated weighing and feedback system with pneumatic valve control, it ensures exceptional filling accuracy and reliability. Constructed with 316L stainless steel to meet GMP standards, this system is designed for seamless operation in large-scale food and beverage production environments.
Key Features
Automation Features
- Automated weighing and feedback system
- Pneumatic valve control
- Photoelectric sensor integration (no bottle, no fill)
- High-speed capping mechanism
- Drip-prevention technology
- Material Construction
- 316L Stainless SteelGMP Compliant
Technical Specifications
Filling Accuracy
2 g
Accuracy
Model Specifications
| Model | Filling Valves | Volume Range (Max) | Speed (BPH) |
|---|---|---|---|
| XLOGX24A | 24 | 5L | 6,000 |
| XLOGX24B | 24 | 10L | 3,000 |
| XLOGX16A | 16 | 2.5L | 6,000 |
| XLOGX16C | 16 | 5L | 4,000 |
| XLOGX32 | 32 | 10L | 4,000 |
